AX7Z020B Dev Board & Kit with AMD Zynq™ 7000 SoC XC7Z020
EIC Product Code: AX7Z020B
The AX7Z020B SoC development board equipped with the AMD Zynq™ 7000 SoC-series device with fast DDR3 SDRAM, QSPI Flash, Gigabit Ethernet, CAN/RS485, HDMI Output, suitable for Industrial, Medical, Automotive, Video and Image Processing, Control & Instrumentation and Communication, etc.
Product Description
The AX7Z010B/AX7Z020B SoC development board equipped with the AMD/Xilinx Zynq™ 7000 SoC-series device, delivers standout performance with fast DDR3 SDRAM, QSPI Flash, Gigabit Ethernet, CAN/RS485, HDMI Output.
Applications
Automotive
● Road Sign Recognition
● ADAS
● Smart Transportation
Communication Network
● Ethernet Backhaul
● Small Cell Baseband
● Network Switch
● Flexible radio platform
Industrial
● Motor control
● Industrial Control
● Industrial IoT
● Instrumentation
● Smart Grid
Video and Image Processing
● Professional Cameras
● Computer Vision
● Machine Vision
Medical
● Endoscop
● Ultrasound, CT, MRI
Key Features
System-on-Module
● AMD/Xilinx Zynq™ 7000 SoC:
◆ ARM® dual-core Cortex™-A9 up to 767 MHz (AX7Z010B is 676MHz)
◆ Artix 7 28nm FPGA fabric● Pluggable module with2x Panasonic board-to-board connectors
● 1 GByte (32-bit) DDR3 SDRAM on PS (AX7Z010B is 512MByte (32-bit) DDR3 )
● 32 MB QSPI FlashBase Board
● 2 x CAN interface on ps
● 2 x RS485 interface (1 x PS + 1 x PL)
● 1 x HDMI out
● 1 x Gigabit Ethernet (1 x PS)
● 1 x MIPI in (only for Ax7Z020B)
● 1 x USB2.0(Host)
● 1 x USB to UART on PS
● 1 x JTAG
● 2 x 40-pin expansion port (40 pin 2.54mm spacing, with 34 IOs, connected to ALINX modules such as binocular cameras, TFT LCD screens, high-speed AD modules, etc.)
● 2 x AD in
● 1 x Micro SD
● 2 x 256Byte EEPROM 24LC04
● 1 x RTC DS1338(Real-time Clock)
● 1 x Temperature sensor LM75
● LED (1 x PWR + 1 x PS LED + 1 x PL LED)
● 5V single supply
● Dimensions: 130 x 90 mm form factor
Development Board Features
Featuring the AMD/Xilinx's Zynq™ 7000 SoC XC7Z020-2CLG400I Adaptive SoC
Design-in Kit – The Fast Way to the Market, to get started with development straight out of the box.
The ALINX development board help shorten time-to-market for any AMD/Xilinx Zynq™ 7000 SoC based application.
* The AX7Z020B development board consists of a AC7Z020 SoM and base board. If you want to purchase AC7Z020 SoM separately.
Please check the Relevant Products at the bottom of the page and click to learn more details.
What's Inside the Box
ALINX AMD Xilinx Zynq™ 7000 SoC XC7Z020 development board and Some accessories
| System-on-Module | 1 | Base Board | 1 |
|---|---|---|---|
| Mini USB Cable | 1 | USB Downloader Cable / set | 1 |
| 5V Power Adapter | 1 | Acrylic board | 1 |
| TF Card | 1 | Card Reader | 1 |
